	Your Location： Home > Product > Open-loop Style > A Series













            HEC-A8 Series





                Publish Time：2012/7/25   |    Click：1196













      Electrical characteristics ：
      Type
      HEC100-A8
      HEC200-A8
      HEC300-A8
      HEC400-A8
      Rated Current
      100A
      200A
      300A
      400A
      Linear Range
      300A
      400A
      500A
      600A
      Output Voltage
      4V 、 5V
      Accuracy
      ±1%
      Offset Voltage
      ± 20mV
      Hysteresis Error
      ± 15mV
      Temperature Drift
      0.03%/ ℃
      0.025%/ ℃
      Response Time
      ＜ 7μS di/dt=50A/μS
      Power Supply
      ± 12V 、± 15V （± 5% ）
      Current Consumption 18mA
      Isolation 3KV AC 50Hz/min
      Operating Temperature Range -10 ℃ ～ +80 ℃
      Storage Temperature Range -25 ℃ ～ +85 ℃
