| HEC-E6 Series |
|
Publish Time：2012/7/25 | Click：1216
|
|
Electrical characteristics ：Type | HEC100-E6 | HEC200-E6 | HEC300-E6 | HEC500-E6 | HEC600-E6 | HEC800-E6 | HEC1000-E6 | Rated Current | ±100A | ±200A | ±300A | ±500A | ±600A | ± 800A | ± 1000A | Linear Range | 1.2 times of the maximum of measuring range | Output Voltage | ±4V 、 5V or 0-20mA/4-20mA output current | Accuracy | ±1% | Offset Voltage | ±20mV | | Hysteresis Error | ±10mV | Temperature Drift | 0.025%/ ℃ | Response Time | ＜ 10μS ??di/dt=50A/μS | Power Supply | ± 12V 、± 15V （± 5% ） | Current Consumption | ±25mA | Isolation | 3KV DC 50Hz/min | Operating Temperature Range |
-10 ℃ ～ + 80 ℃
| Storage Temperature Range |
-25 ℃ ～ + 85 ℃ |

|
| |
|
|
|
