            HEC-D4 Series





                Publish Time：2012/7/25   |    Click：1068












               Electrical characteristics ：
      Type
      HEC400-D4
      HEC500-D4
      HEC600-D4
      HEC800-D4
      HEC1000-D4
      Rated Current
      ± 400A
      ±500A
      ±600A
      ±800A
      ±1000A
      Output Current
      ±80mA
      ±100mA
      ±120mA
      ±160mA
      ±200mA
      Linear Range
      1.5 times of the maximum of measuring range
      Accuracy
      0.5%
      Degree of Linearity                                                                      0.1%
      Turn Ratio
      		                                                                    1:5000
      Offset Current
      ±0.2mA
      Hysteresis Error
      ±0.1mA
      Temperature Drift
      0.025%/ ℃
      Response Time
      ＜ 1μS  di/dt=100A/μS
      Power Supply
      ± 12V 、± 15V 、± 24V （± 5% ）
      Current Consumption
      ±28mA plus output current
      Isolation
      3KV  AC  50Hz/min
      Operating Temperature Range

      -10 ℃ ～ +80 ℃
      Storage Temperature Range

      -25 ℃ ～ +85 ℃
