Type

HEC0.01-E4

HEC0.02-E4

HEC0.05-E4

HEC0.1-E4

HEC0.5-E4

HEC1-E4

HEC2 -E4

Rated Current

±10mA

±20mA

±50mA

±100mA

±500mA

± 1A

± 2A

Linear Range

2 times of the maximum of measuring range

Output Voltage

±4V 、 5V? or 0-20mA/4-20mA output current

Accuracy

±1%

Offset Voltage

±40mV

Temperature Drift

0.05%/ ℃

Response Time

＜ 120mS

Power Supply

± 12V 、± 15V （± 5% ）

Current Consumption

Isolation

Operating Temperature Range

                                                           -10 ℃ ～ + 80 ℃

Storage Temperature Range
