	Your Location： Home > Product > Voltage Sensor Style > F Series













            HEC-F6 Series





                Publish Time：2012/7/25   |    Click：881













      Electrical characteristics ：
      Type
      HEC500V-F6
      Rated Current
      0~±10mA
      Linear Range
      0～±14mA
      Output Current
      0~25mA
      Load resistance
      input current ±10mA,   100~350Ω    supply voltage ±15V
      input current ±14mA,   100~190Ω    supply voltage ±15V
            Accuracy
      ±0.6%
      Degree of Linearity
      ＜0.2%
      Turn Ratio
      2500:1000
      Offset Voltage
      ±0.1mA ±0.20mA(max)
      Temperature Drift
      ±0.20mA    ±0.64mA(max )   -10 ℃ ～ +70 ℃
      Response Time
      ＜40μS
      Power Supply
      ± 12V 、± 15V （± 5% ）
      Current Consumption
      10mA plus output current
       Isolation
      2.5KV DC
         Internal Resistance
      original coil 250Ω
      secondary coil 110Ω
      Operating Temperature Range
      0℃ ～ +70℃
      Storage Temperature Range
      -10 ℃ ～ +85 ℃
